Portable Wireless Ultrasound Scanner Medbridge Echo Wave CB-20 Convex

MedBridge
Portable Wireless Ultrasound Scanner Medbridge Echo Wave CB-20 Convex

Click on an image to open Gallery

MOD: 18972-02
15-30 days
  • Price: 4,960.00€
  • 4,000.00€ + TAX 24%

Brand:MedBridge


Description

Portable Wireless Ultrasound Scanner Medbridge Echo Wave CB-20 Convex



MedBridge Echo Wave CB-20 is a specialized portable convex ultrasound probe, designed for high-resolution imaging of deep anatomical structures, such as abdominal organs, the urinary system, and for obstetric and gynecological examinations.

Its low frequency and wide beam angle allow imaging of large fields with good penetration, making it suitable for patients with higher body weight or difficult access.

The wireless functionality offers complete freedom of movement, reduces preparation time, limits contamination risk, and facilitates patient access from different angles. Connection to portable devices (tablet or smartphone) enables instant high-resolution imaging, storage, sharing, and seamless integration with electronic medical records.

Overall, the Echo Wave CB-20 is an ergonomic, efficient, and technologically advanced diagnostic tool for the modern physician.

Advantages & Uses

    • Deep anatomical assessment: abdominal organs, urinary system.
    • Obstetric & gynecological exams: precise fetal and gynecological imaging.
    • Large field imaging with good penetration for difficult cases.
    • Wireless operation & portability: ideal for emergency cases, ICU, home visits, remote areas.
    • Rapid point-of-care diagnosis and immediate documentation.

  •

    Imaging Functions

    • Modes: B Mode, B+B Mode, B+M Mode, M Mode
    • Doppler: Color Doppler, Power Doppler, Pulse Wave Mode
    • Measurements: Angle, Area, Automatic Vessel Flow Measurement, Circumference, Distance, Heart Rate, Length, Time, Trace, Velocity, Volume
  •




    Technical Specifications

    • Probe Type: Convex
    • Transducer Type: Single Probe
    • Elements: Dual 128
    • Frequency: 2.5–3.5 MHz, 3.2–5 MHz, 7.5–10 MHz
    • Frame Rate: 18–24 F/S
    • Convex Depth: 90–240 mm, 90–305 mm
    • Linear Depth: 20–100 mm
    • Gain: 40–110 dB
    • DICOM / PACS Support: Yes
    • Connectivity: USB, WiFi 2.4GHz (802.11n)
    • Compatible Devices: Android OS 11,12,13+, iPhone/iPad OS 14,15,16+, Windows 10+
    • Waterproof: IPX5
    • Weight: 165 g
    •  Charging Type: Micro USB & Wireless Charging
    • Battery Type: 2800 mAh
    • Battery Life: Stand-by 12 hours, full operation up to 3 hours
    • Battery Replaceable: Yes, user-replaceable
    • Warranty: 6 months full accidental coverage, 1-year standard warranty

  •

    Recommended Applications

    • Vascular Surgery
    • Radiology
    • Anesthesiology
    • Emergency Medicine
    • Veterinary Medicine
    • Obstetrics & Gynecology
    • Urology
    • Pathology

  •

    Benefits

    • Portability & ease of use: Compact, lightweight, easy transport, plug & play, out-of-hospital use.
    • Speed & reliability: Immediate point-of-care diagnosis.
    • Cost efficiency: More affordable than traditional ultrasound systems with high ROI.
    • High ergonomics: Easy handling, comfortable imaging of large areas.
    • Telemedicine capability: Instant image sharing for remote diagnosis.
    • Support for interventional procedures: Accurate guidance and safe execution.
    • Critical condition diagnostics: FAST Scan, Lung Ultrasound, Echocardiography.
    • Use of new technologies & AI: Automatic measurements (in future versions), improving quality and diagnostic capability.
